Load capacity and design
- The loading capacity of each axle can reach 12 tons or 14 tons, suitable for a driving speed of 80 kilometers per hour.
- Adopting a lightweight high tension steel chassis, optimizing the structure to increase the effective load while reducing maintenance costs.
- Equipped with wide excavation slots and large loading space to enhance compatibility with oversized cargo; The steering angle is large and the steering system has been optimized to improve maneuverability and reduce tire wear.
key configuration
Suspension system: Optional mechanical suspension or pneumatic suspension to ensure transportation stability.
Braking and Electrical: Dual line braking system, 24V electrical system (7 Pole plug), ensuring driving safety.
Materials and Customization: The main body is made of steel, and the dimensions (such as length and width) can be customized according to needs, with optional colors.
Parameter List
|
Type |
Semi-Trailer |
Max Payload |
>30000 kg |
|
Brand Name |
HENGTONG |
Place of Origin |
SHANDONG,China |
|
Use |
Truck Trailer |
Material |
Steel |
|
Size |
13000*3000*1760mm |
Function |
Heavy Duty Transportation |
|
Axle |
2-3-4axles |
Main Beam |
submerged arc welding |
|
Landing Gear |
JOST A300 |
Tire |
12R22.5 |
|
King pin |
90# |
Suspension |
Mechanical Suspension Air Suspension |
|
MOQ |
1 Set |
Brand |
HT |
|
Product name |
Lowbed Semi Trailer |
||
|
Overall dimension |
13000-18000*3000-3500*1760mm |
||
|
Load capacity |
60-80T |
||
|
Axles |
3 axle,13T/16T, FUWA / BPW / HT/SAF Other Brand |
||
|
Tire |
8.25R20/10.00R20/11.00R20/12.00R20 |
||
|
Kingpin |
90# |
||
|
Landing gear |
JOST brand |
||
|
Brake |
Dual Line braking system |
||
|
Lights |
Rear electrical lighting, brake lights, indicators, fog lights and reversing light |
||
|
Painting |
Sand blasting before painting. One coat of primer, anti corrosion. Two coats of finish painting. Color advised by customer |
||
|
Packing |
Polish with wax |
||
