Lowbed Lowboy Trailer – The Premier Heavy Equipment Transport Solution
Engineered for Extreme-Duty Hauling
Our Lowbed Lowboy Trailer sets the industry benchmark for transporting oversized and ultra-heavy loads, including construction machinery, mining equipment, and wind turbine components. With its ultra-low deck height and reinforced structure, it complies with DOT, EN 12642-XL, and ASME B30.22 regulations, ensuring safe and efficient transport of cargo up to 150 metric tons.
Key Features & Benefits
1. Ultra-Low Profile Design
● Deck Height as Low as 18 Inches: Optimized for bridge clearance and load stability.
● Hydraulic Detachable Gooseneck (HDG): Enables quick setup and superior maneuverability.
● Multi-Stage Ramps: Adjustable ramp angles (8°–15°) for easy loading of crawler equipment.
2. Unmatched Load Capacity & Durability
● High-Tensile Steel Construction: 12mm thick main beams with 750MPa yield strength.
● Modular Axle Systems: 3–8 axles with BPW/Goldhofer suspension (80–150T capacity).
● Anti-Slip Deck Surface: 10mm diamond plate with integrated D-ring tie-downs (every 2 feet).
3. Smart & Safe Transport
● Real-Time Load Monitoring: Wireless sensors display weight distribution (±0.5% accuracy).
● Telematics Integration: GPS tracking, route optimization, and automated permit compliance.
● 360° LED Lighting: Compliant with ECE R48 for maximum visibility.
Why Choose Our Lowbed Lowboy Trailer?
● Global Compliance: Meets STGO/OSOW regulations in 30+ countries.
● Custom Configurations: Available in 40–65ft lengths with optional jeep dollies or extendable decks.
● Lifetime Support: 24/7 technical assistance with a 10-year structural warranty.Contact our heavy haul experts today for a tailored solution!
Parameter List
|
HYDRAULIC DETACHING NECK LOWBED SEMI TRAILER |
|||||||
|
MODEL |
HT9300EXTL |
||||||
|
DIMENSION(OPTIONAL) |
AXLE NO. |
RATED LOAD (T) |
TIRE NO. |
TIRE SIZE |
|||
|
DIMENSION MADE BY CUSTOMER MACHINE SIZE, STANDARD LENGTH IS 13500MM (CONTACT SUPPLIER FOR MORE) |
1 |
20 |
4 |
825R201000R20 1100R201200R20 12R22.5(OTHER SIZE/ SINGLE SUPER TIRE CONTACT WITH SUPPLIER) |
|||
|
2 |
40 |
8 |
|||||
|
3 |
60 |
12 |
|||||
|
4 |
80 |
16 |
|||||
|
5 |
100 |
20 |
|||||
|
WHEEL BASE (MM) |
1310 |
||||||
|
AXLE |
13/16/20/25T |
||||||
|
SUSPENSION |
HEAVY DUTY MECHANIC SUSPENSION WITH LEAF SPRINGS |
||||||
|
MAIN BEAM MATERIAL |
Q345B MANGANESE PLATES,AUTOMATIC SUBMERGED ARC WELDED |
||||||
|
BRAKE SYSTEM |
DUAL LINE BRAKING SYSTEM WITH AUTOMATIC BRAKING SYSTEM/CHAMBERS |
||||||
|
KINGPIN |
2'OR 3.5'INTERCHANGEABLE |
||||||
|
LANDING GEAR |
28T LOADING CAPACITY WITH 80T STATIC LIFTING CAPACITY. |
||||||
|
PLATFORM |
4-6 MM DIAMOND STEEL PLATE |
||||||
|
BRAKE SYSTEM |
DUAL LINES BRAKING SYSTEM WITH AUTOMATIC AIR CHAMBERS |
||||||
|
ELECTRICAL SYSTEM |
24V,7CORE SOCKET,LIGHTS ACCORDING TO EUROPEAN STANDARDS. |
||||||
|
MAINBEAM SIZE |
UPPER WING PLATE |
14MM |
|||||
|
LOWER WING PLATE |
16MM |
||||||
|
STANDING PLATE |
8 MM |
||||||
|
HEIGHT |
500-520MM |
||||||
|
PIN HEIGHT |
ACCORDING TO THE HEIGHT OF THE TRACTOR SADDLE. |
||||||
